CVap® Comparison

CVap® Holding

 ModelSheet PanHalf Sheet PanHotel Pan (2.5″ Deep)HeightDepthWidthVoltsPhaseWattsAmpsNEMACategory
HOV3-05UV5101039.22″ (996mm)34.23″ (869mm)27.70″ (704mm)1201229219.15-20PCVap® Holding
HOV3-14UV
14282873.02″ (1855mm)34.23″ (869mm)27.70″ (704mm)1201229219.15-20PCVap® Holding
HOV5-04HP
N/A4436.38″ (924mm)26.45″ (672mm)20″ (508mm)1201140811.755-20PCVap® Holding
HOV5-04UV
48835.70″ (907mm)34.23″ (869mm)27.70″ (704mm)1201229219.15-20PCVap® Holding
HOV5-05SP
510N/A39.22″ (996mm)34.23″ (869mm)24.70″ (627mm)1201229219.15-20PCVap® Holding
HOV5-05UV
5101039.22″ (996mm)34.23″ (869mm)27.70″ (704mm)1201229219.15-20PCVap® Holding
HOV5-14SP
1428N/A73.02″ (1855mm)34.23″ (869mm)24.70″ (627mm)1201229219.15-20PCVap® Holding
HOV5-14UV
14282873.02″ (1855mm)34.23″ (869mm)27.70″ (704mm)1201229219.15-20PCVap® Holding
RTV5-04
RTV5-04UV
48835.70″ (907mm)34.23″ (869mm)27.70″ (704mm)208 / 208 / 2401 / 3 / 17212 / 7212 / 721234.7 / 23.7 / 306-50P / 15-30P / 6-50PCVap® Retherm
RTV5-05UV
5101039.22″ (996mm)34.23″ (869mm)27.70″ (704mm)208 / 208 / 2401 / 3 / 17212 / 7212 / 721234.7 / 23.7 / 306-50P / 15-30P / 6-50PCVap® Retherm
RTV5-05UV-ST
10 (2×5)20 (2×10)20 (2×10)76.8″ (1950mm)34.23″ (869mm)27.70″ (704mm)208 / 208 / 2401 / 3 / 17212 / 7212 / 721234.7 / 23.7 / 306-50P / 15-30P / 6-50PCVap® Retherm
RTV5-14UV
14282873.02″ (1855mm)34.23″ (869mm)27.70″ (704mm)208 / 2403 / 310815 / 1081533.7 / 27.215-50P / 15-50PCVap® Retherm
RTV7-04UV
48835.70″ (907mm)34.23″ (869mm)27.70″ (704mm)208 / 208 / 2401 / 3 / 17212 / 7212 / 721234.7 / 23.7 / 306-50P / 15-30P / 6-50PCVap® Retherm
RTV7-05UV
5101039.22″ (996mm)34.23″ (869mm)27.70″ (704mm)208 / 208 / 2401 / 3 / 17212 / 7212 / 721234.7 / 23.7 / 306-50P / 15-30P / 6-50PCVap® Retherm
RTV7-05UV-ST
10 (2×5)20 (2×10)20 (2×10)76.8″ (1950mm)34.23″ (869mm)27.70″ (704mm)208 / 208 / 2401 / 3 / 17212 / 7212 / 721234.7 / 23.7 / 306-30P / 15-20P / 6-30PCVap® Retherm
RTV7-14UV
14282873.02″ (1855mm)34.23″ (869mm)27.70″ (704mm)208 / 2403 / 310815 / 1081533.7 / 27.215-50P / 15-50PCVap® Retherm
CHV5-04HP
N/A4436.38″ (924mm)26.45″ (672mm)20″ (508mm)208 / 2401 / 12400 / 240011.5 / 106-20P / 6-20PCVap® Cook and Hold
CHV5-04UV
48835.70″ (907mm)34.23″ (869mm)27.70″ (704mm)208 / 2401 / 14803 / 480323 / 206-30P / 6-30PCVap® Cook and Hold
CHV5-05UV
5101039.22″ (996mm)34.23″ (869mm)27.70″ (704mm)208 / 208 / 2401 / 3 / 14803 / 4803 / 480323 / 10.5 / 206-30P / 15-20P / 6-30PCVap® Cook and Hold
CHV5-05UV-ST
10 (2×5)20 (2×10)20 (2×10)76.80″ (1950mm)34.23″ (869mm)27.70″ (704mm)208 / 208 / 2401 / 3 / 14803 / 4803 / 480323 / 10.5 / 206-30P / 15-20P / 6-30PCVap® Cook and Hold
CHV5-14UV
14282873.02″ (1855mm)34.23″ (869mm)27.70″ (704mm)208 / 208 / 2401 / 3 / 17503 / 7503 / 750336.1 / 23.7 / 31.16-50P / 15-30P / 6-50PCVap® Cook and Hold
CHV7-04HP
N/A4436.38″ (924mm)26.45″ (672mm)20″ (508mm)208 / 2401 / 12400 / 240011.5 / 106-20P / 6-20PCVap® Cook and Hold
CHV7-04UV
48835.70″ (907mm)34.23″ (869mm)27.70″ (704mm)208 / 2401 / 14803 / 480323 / 206-30P / 6-30PCVap® Cook and Hold
CHV7-05UV
5101039.22″ (996mm)34.23″ (869mm)27.70″ (704mm)208 / 208 / 2401 / 3 / 14803 / 4803 / 480323 / 10.5 / 206-30P / 15-20P / 6-30PCVap® Cook and Hold
CHV7-05UV-ST
10 (2×5)20 (2×10)20 (2×10)76.80″ (1950mm)34.23″ (869mm)27.70″ (704mm)208 / 208 / 2401 / 3 / 14803 / 4803 / 480323 / 10.5 / 206-30P / 15-20P / 6-30PCVap® Cook and Hold
CHV7-14UV
14282873.02″ (1855mm)34.23″ (869mm)27.70″ (704mm)208 / 208 / 2401 / 3 / 17503 / 7503 / 750336.1 / 23.7 / 31.36-50P / 15-30P / 6-50PCVap® Cook and Hold

CVap® Cook and Hold​

Model
Sheet Pan
Half Sheet Pan
Hotel Pan (2.5″ Deep)
Height
Depth
Width
Volts
Phase
Watts
Amps
NEMA
CHV5-04HP
N/A
4
4
36.38″ (924mm)
26.45″ (672mm)
20″ (508mm)
208 / 240
1 / 1
2400 / 2400
11.5 / 10
6-20P / 6-20P
CHV5-04UV
4
8
8
35.70″ (907mm)
34.23″ (869mm)
27.70″ (704mm)
208 / 240
1 / 1
4803 / 4803
23 / 20
6-30P / 6-30P
CHV5-05UV
5
10
10
39.22″ (996mm)
34.23″ (869mm)
27.70″ (704mm)
208 / 208 / 240
1 / 3 / 1
4803 / 4803 / 4803
23 / 10.5 / 20
6-30P / 15-20P / 6-30P
CHV5-05UV-ST
10 (2×5)
20 (2×10)
20 (2×10)
76.80″ (1950mm)
34.23″ (869mm)
27.70″ (704mm)
208 / 208 / 240
1 / 3 / 1
4803 / 4803 / 4803
23 / 10.5 / 20
6-30P / 15-20P / 6-30P
CHV5-14UV
14
28
28
73.02″ (1855mm)
34.23″ (869mm)
27.70″ (704mm)
208 / 208 / 240
1 / 3 / 1
7503 / 7503 / 7503
36.1 / 23.7 / 31.1
6-50P / 15-30P / 6-50P
CHV7-04HP
N/A
4
4
36.38″ (924mm)
26.45″ (672mm)
20″ (508mm)
208 / 240
1 / 1
2400 / 2400
11.5 / 10
6-20P / 6-20P
CHV7-04UV
4
8
8
35.70″ (907mm)
34.23″ (869mm)
27.70″ (704mm)
208 / 240
1 / 1
4803 / 4803
23 / 20
6-30P / 6-30P
CHV7-05UV
5
10
10
39.22″ (996mm)
34.23″ (869mm)
27.70″ (704mm)
208 / 208 / 240
1 / 3 / 1
4803 / 4803 / 4803
23 / 10.5 / 20
6-30P / 15-20P / 6-30P
CHV7-05UV-ST
10 (2×5)
20 (2×10)
20 (2×10)
76.80″ (1950mm)
34.23″ (869mm)
27.70″ (704mm)
208 / 208 / 240
1 / 3 / 1
4803 / 4803 / 4803
23 / 10.5 / 20
6-30P / 15-20P / 6-30P
CHV7-14UV
14
28
28
73.02″ (1855mm)
34.23″ (869mm)
27.70″ (704mm)
208 / 208 / 240
1 / 3 / 1
7503 / 7503 / 7503
36.1 / 23.7 / 31.3
6-50P / 15-30P / 6-50P

CVap® Retherm​

Model
Sheet Pan
Half Sheet Pan
Hotel Pan (2.5″ Deep)
Height
Depth
Width
Volts
Phase
Watts
Amps
NEMA
RTV5-04
RTV5-04UV
4
8
8
35.70″ (907mm)
34.23″ (869mm)
27.70″ (704mm)
208 / 208 / 240
1 / 3 / 1
7212 / 7212 / 7212
34.7 / 23.7 / 30
6-50P / 15-30P / 6-50P
RTV5-05UV
5
10
10
39.22″ (996mm)
34.23″ (869mm)
27.70″ (704mm)
208 / 208 / 240
1 / 3 / 1
7212 / 7212 / 7212
34.7 / 23.7 / 30
6-50P / 15-30P / 6-50P
RTV5-05UV-ST
10 (2×5)
20 (2×10)
20 (2×10)
76.8″ (1950mm)
34.23″ (869mm)
27.70″ (704mm)
208 / 208 / 240
1 / 3 / 1
7212 / 7212 / 7212
34.7 / 23.7 / 30
6-50P / 15-30P / 6-50P
RTV5-14UV
14
28
28
73.02″ (1855mm)
34.23″ (869mm)
27.70″ (704mm)
208 / 240
3 / 3
10815 / 10815
33.7 / 27.2
15-50P / 15-50P
RTV7-04UV
4
8
8
35.70″ (907mm)
34.23″ (869mm)
27.70″ (704mm)
208 / 208 / 240
1 / 3 / 1
7212 / 7212 / 7212
34.7 / 23.7 / 30
6-50P / 15-30P / 6-50P
RTV7-05UV
5
10
10
39.22″ (996mm)
34.23″ (869mm)
27.70″ (704mm)
208 / 208 / 240
1 / 3 / 1
7212 / 7212 / 7212
34.7 / 23.7 / 30
6-50P / 15-30P / 6-50P
RTV7-05UV-ST
10 (2×5)
20 (2×10)
20 (2×10)
76.8″ (1950mm)
34.23″ (869mm)
27.70″ (704mm)
208 / 208 / 240
1 / 3 / 1
7212 / 7212 / 7212
34.7 / 23.7 / 30
6-30P / 15-20P / 6-30P
RTV7-14UV
14
28
28
73.02″ (1855mm)
34.23″ (869mm)
27.70″ (704mm)
208 / 240
3 / 3
10815 / 10815
33.7 / 27.2
15-50P / 15-50P
